Cart 2 india

Specification
Brand : FUTTFUTTFU
BulletPoint1 : It is a measurement of fluid weight per unit of volume. This measurement is often referred to asmud . Weight and is reported as Gravity gms/cm3 or as Specific gallon, pounds, the primary function of monitoring density is to control formation pressures and minimize loss of returns.
BulletPoint2 : Applicable occasions: Mainly used for measuring the density of drilling fluids and other liquid substance density instruments, widely used in major oil fields, geological exploration, and laboratories for liquid density analysis and measurement.
BulletPoint3 : Liquid density meter, also known as density meter, is made of refined stainless steel material. The stainless steel liquid density meter is sturdy and durable, resistant to impact, with a fine surface, stable measurement data, and direct reading of metric values.
BulletPoint4 : Its scale adopts anti-corrosion allumen oxidation treatment and stainless steel wrapping.
BulletPoint5 : design to make the scale clear and accurate. The instrument is lightweight and durable.
ExternallyAssignedProductIdentifier : 7433247480701
ExternallyAssignedProductIdentifier1 : 0714855589084
ExternallyAssignedProductIdentifier2 : 714855589084
IncludedComponents : Mud Scale and Mud Sand Content Test
ItemName : Mud Scale and Mud Sand Content Test Meter Slurry Viscometer Drilling mud Liquid Density Density Density Meter Measurment Range:0.1-1.5g/cm3
ItemPackageDimensions_Height : 37 centimeters
ItemPackageDimensions_Length : 42 centimeters
ItemPackageDimensions_Width : 36 centimeters
ItemPackageQuantity : 1
ItemShape : Rectangular
ItemTypeKeyword : science-lab-viscometers
Manufacturer : FUTTFUTTFU
MeasurementAccuracy : 1%
ModelNumber : Mud Scale and Mud Sand Content Test
NumberOfItems : 1
PartNumber : Mud Scale and Mud Sand Content Test
ProductDescription : Operating procedures

1. Mud should be injected into the mud cup, flush with the cup mouth, without leaving any bubbles. Gently cover the cup cover, and excess mud and air should be discharged from the small hole in the middle of the cup cover. Then, wipe the spilled mud clean.

2. Then place the main blade of the lever on the main blade pad of the base, and slowly move the weight. When the water bubble is in the center, the lever is in a horizontal state, and the scale shown on the left side of the weight is the mud specific gravity.

3. If the mud specific gravity needs to be measured within the range of 2-3 grams/cm3, the balance cylinder cover needs to be unscrewed, and then the counterweight needs to be inserted. The measurement can be done by screwing on the threaded cover. (The measurement method and steps are the same as above) The instrument should be rinsed, wiped, and cleaned after use.

easy to take with and read, which is used in some big oil field, geological survey and labs.

widely to analyze and test fluid’s density.
Model Number:Sand Content Kit
Power:Electronic
Product Name:Mud Scale And Mud Sand Content Test
Meter Slurry Viscometer
Material:Stainless Steel
Color:Gray
Measurment range:0.1-1.5g/cm3（0.8-131b/gal）
Measuring accuracy:0.01g/cm3(0.1lb/gal)
Mudcup capacity:140/cm³
Outline Dimension:540*110*110mm
Net Weight:2.2Kg
ProductSiteLaunchDate : 2024-01-08T14:00:01.071Z
Style : Modern
SupplierDeclaredDgHzRegulation : not_applicable
SupplierDeclaredHasProductIdentifierExemption : 1
UnitCount : 0.0353
