Product Information
Editorial Review
2-Port RS232 to Ethernet Data Gateway with virtual com software addresses the need to connect individual RS-232C devices, such as PLCs, meters, sensors, to an IP-based Ethernet LAN. It makes your application software to access serial devices anywhere on a local area network or the Internet. It is easy to install or remotely through a variety IP addressing methods (UDP, IP, TCP, ICMP, HTTP, DHCP, ARP-Ping). It is ideal for applications requiring serial port environments and network device management. Features Provides 2-Port Serial RS-232C over Ethernet Provides 2 DB9 RS-232C Male Connectors RS-232C Speed from 300bps to 115.2Kbps Provides one 10/100Mbps, RJ45 LAN Port Supports Setup and Connect Passwords Supports Standard Windows Socket Protocol Provides TCP Server, TCP Client, and UDP Built-in Watch Dog Feature +12VDC DC Jack Power Input Connector Includes Wall Mounting Kit Specifications LAN Port: Ethernet: 10/100 Mbps, RJ45 connector Protocols: UDP, IP, TCP, ICMP, HTTP, DHCP, ARP-Ping The Serial interface provides 2 DB9 RS-232 connectors. The key benefits are: RS-232 Connector: DB9 male Parity: None, Even, Odd Data bits: 5,6,7,8 Speed: 300bps to 115.2Kbps Watch Dog Function A built-in watch dog function is designed to reset the MSD-SRF4X when the hardware/software hang because some other unknown causes. Power Requirements +12VDC from DC Jack Power Input Connector Environmental: Operating Temp.: 0 to 55C (32 to 131F) Storage Temp: -20 to 85C (-4 to 185F) Operating Humidity: 5 to 95% RH
Features
1) Provides 2 RS-232C Ports over Ethernet
2) Provides one 10/100Mbps, RJ45 LAN Port
3) Provides TCP Server, TCP Client, and UDP Built-in Watch Dog Feature
4) Addresses the need to connect individual RS-232C devices
5) Supports Setup and Connect Passwords
Specification
Binding : Electronics
Brand : SERIALGEAR
Color : Black
EAN : 0729440691783
Label : SerialGear
Manufacturer : SerialGear
Model : MSD-SRF2X
ProductGroup : PC Accessory
ProductTypeName : NETWORKING_DEVICE
Publisher : SerialGear
Studio : SerialGear
Title : SerialGear 2-Port RS-232 to Ethernet Gateway
2-Port RS232 to Ethernet Data Gateway with virtual com software addresses the need to connect individual RS-232C devices, such as PLCs, meters, sensors, to an IP-based Ethernet LAN. It makes your application software to access serial devices anywhere on a local area network or the Internet. It is easy to install or remotely through a variety IP addressing methods (UDP, IP, TCP, ICMP, HTTP, DHCP, ARP-Ping). It is ideal for applications requiring serial port environments and network device management. Features Provides 2-Port Serial RS-232C over Ethernet Provides 2 DB9 RS-232C Male Connectors RS-232C Speed from 300bps to 115.2Kbps Provides one 10/100Mbps, RJ45 LAN Port Supports Setup and Connect Passwords Supports Standard Windows Socket Protocol Provides TCP Server, TCP Client, and UDP Built-in Watch Dog Feature +12VDC DC Jack Power Input Connector Includes Wall Mounting Kit Specifications LAN Port: Ethernet: 10/100 Mbps, RJ45 connector Protocols: UDP, IP, TCP, ICMP, HTTP, DHCP, ARP-Ping The Serial interface provides 2 DB9 RS-232 connectors. The key benefits are: RS-232 Connector: DB9 male Parity: None, Even, Odd Data bits: 5,6,7,8 Speed: 300bps to 115.2Kbps Watch Dog Function A built-in watch dog function is designed to reset the MSD-SRF4X when the hardware/software hang because some other unknown causes. Power Requirements +12VDC from DC Jack Power Input Connector Environmental: Operating Temp.: 0 to 55C (32 to 131F) Storage Temp: -20 to 85C (-4 to 185F) Operating Humidity: 5 to 95% RH
