Specification
Brand : Walfront
BulletPoint1 : Multi : The switch supports multiple functions, including short circuit, overload, phase loss and undervoltage , which is and
BulletPoint2 : Advanced Technology: Double row composite contacts, horizontal pull structure, micro motor advanced energy storage and microelectronic control technology are adopted to basically realize no arc crossing.
BulletPoint3 : 4 Functions: This switch has 4 functions, emergency manual operation, electric remote control operation, emergency disconnection under automatic control, and automatic control
BulletPoint4 : Applicable Scenarios: The switch can be used in homes and public places, especially in office buildings and public places that need fire .
BulletPoint5 : The load isolation actuating switch is equipped with a mechanical interlock device to ensure the of the main and standby power supplies without mutual interference.
CircuitType : 2-way
Color : 63A 4P-Style 1
ConnectivityProtocol : X-10
ConnectorType : Screw Terminal
ControlMethod : remote
CurrentRating : 160 amps
IncludedComponents : 1* Smart AC Module
InternationalProtectionRating : IP54
ItemName : Walfront Generator Transfer Switch, Automatic Isolated, 400V (160A), 3-Position, Manual & Automatic Operation, IP54 Rated
ItemPackageDimensions_Height : 34.1122 centimeters
ItemPackageDimensions_Length : 18.4912 centimeters
ItemPackageDimensions_Width : 21.0058 centimeters
ItemTypeKeyword : generator-transfer-switches
LightType : LED
Manufacturer : WALFRONT
Material : Polycarbonate
ModelName : Walfront4gn5d1r873-12
ModelNumber : WALFRONT4gn5d1r873-12
MountingType : Wall Mount
NumberOfItems : 1
NumberOfPositions : 2
OperatingVoltage : 220 volts
OperationMode : Automatic
PackageLevel : unit
PartNumber : WALFRONT4gn5d1r873-12
ProductDescription :

Specification:
Item Type: Generator Transfer Switch
Material: PC
Rated Working Voltage: AC400V
Control Voltage: 220V
Rated Isolation Voltage Ui: 1000V
Rated Impulse Withstand Voltage Uimp: 6KV
Rated Short Time Withstand Voltage: 5kA
Usage Category: AC 33B
Rated Production Capacity: 10Ie
Rated Breaking Capacity: 10Ie
Rated Power: 50, 60HZ
Grade: PC
Working Temperature: - 20 to 45 ℃ (24h average value shall not exceed 35 ℃)
Operating Humidity: The average humidity at 40 ℃ shall not exceed 50%, and no condensation is allowed

How to Use:
1. Electric key lock: It controls the control switch inside the line power supply. When the electric lock is opened, the switch can be operated automatically by remote control, and then the electric lock is closed. The switch can only be operated through the handle.
2. Operating handle: When operating the switch, the electric lock must be closed.
3. Mechanical padlock: during maintenance, first use the operating handle to turn the switch to position 0, then pull the padlock mechanism and close the padlock to carry out maintenance: (Pulling the padlock of the mechanism will cut off the power supply of the internal control power switch, and the switch cannot be in the electric position or driven manually.)
4. Position indication: indicates the position of the working area of the switch (I, 0, II)
5. Control voltage: switch control voltage class 220VAC.
6. Switch body: the front part is line I, connected to mains; The rear is wire II, connected to emergency power supply.

Package List:
1 x Generator Transfer Switch
1 x Handle
2 x Key
1 x Manual
12 x Bolts
12 x Nut

ProductSiteLaunchDate : 2023-01-09T13:07:24.784Z
Size : 160A
SpecificationMet : 1
SupplierDeclaredDgHzRegulation : not_applicable
SupplierDeclaredHasProductIdentifierExemption : 1
SwitchType : Mechanical
TerminalType : Screw
UnitCount : 1
UnspscCode : 39122200
UpperTemperatureRating : 45 degrees_celsius
Wattage : 50 watts
