Specification BatteriesRequired : 1 Brand : CNYST BulletPoint1 : ◆ 8 keyboard button user-friendly design, simple and convenient to carry out; High measurement accuracy and large measurement range; BulletPoint2 : ◆This high-precision ultrasonic thickness gauge is suitable for high-precision thickness measurement of various materials.; Thickness measurement range: 1~260 (Standard Probe 5MHz, Φ10mm) BulletPoint3 : ◆ The display unit can be selected between mm and inch.Automatic calibration of probe zero point, sound speed calibration function; BulletPoint4 : ◆A variety of practical measurement modes: standard measurement mode, scan mode, difference measurement mode, average measurement mode, extreme alarm mode BulletPoint5 : ◆ Power-on self-test function to improve measurement accuracy;Large-capacity data storage: up to 2000 sets of data storage; Color : black IncludedComponents : see the description ItemDisplayWeight : 1.5 kilograms ItemName : CNYST Digital Ultrasonic Thickness Meter Ultrasonic Thickness Measurement with Built-in Sound Speed of 9 Materials Data Saving Mode Range 1~260mm Standard Probe 5MHz Φ10mm ItemPackageDimensions_Height : 10 centimeters ItemPackageDimensions_Length : 35 centimeters ItemPackageDimensions_Width : 25 centimeters ItemTypeKeyword : thickness-gauges Manufacturer : CNYST Material : See the Product Description MeasurementAccuracy : see the description ModelName : FOLOSAFENAR7t5svge9nz ModelNumber : 02024111108 NumberOfItems : 1 PartNumber : 02024111108 ProductDescription : Shipping Policy : Battery and Liquid Not Included During the Shipping Introduction This high-precision ultrasonic thickness gauge is suitable for thickness measurement of various materials. It can be applied to steel, cast iron, aluminum, copper, zinc, quartz, glass, polyethylene, PVC, gray cast iron, ductile iron, etc. The measured thickness of the measured object of the material. It is only necessary to place the probe on the contact surface on the side of the object to be measured, so that the thickness of the measured object can be measured
Festures: The automatic shutdown time can be set according to the user's habits; A variety of practical measurement modes: standard measurement mode, scan mode, difference measurement mode, average measurement mode, extreme alarm mode Built-in sound speed of 9 materials, and can be edited for user convenience zero calibration, single point and two point calibration speed, and direction keys freely adjust the value; User-friendly data saving mode: data can be saved in groups, and the amount of data can be saved in each group. It is not necessary to manually save measurement data, simplifying operations; USB data transmission interface, easy to achieve data export with computer data (data format.txt);
Technical Specifications Thickness measurement range: 1~260mm(Standard Probe 5MHz, Φ10mm) Sound speed of material: 509~18699m/s Measurement accuracy: ±(0.5%H+0.05)mm Display accuracy: 0.01mm or 0.001inch Receive bandwidth: 1MHz ~ 10MHz (-3dB) Measurement frequency: 2 to 20 times / sec (can be set) Power: 3VDC (two AA alkaline batteries)(Battery Not Included In the Package) Screen display: 128×64 dot matrix LCD Working hours: 280 hours (auto mode); 100 hours (backlight on) Operating humidity: 20% to 90% RH size: 136 (L) mm × 72 (W) mm × 20 (H) mm weight: 176g
