Specification
Brand : Sonew
BulletPoint1 : The working status is indicated by the LED indicator, the power indicator is green, and the output relay indicator is red.
BulletPoint2 : The maximum power consumption is 2VA, and the allowable fluctuation range of the power supply is -15%~+10%.
BulletPoint3 : Working power supply voltage AC/DC 24V‑240V, rated power supply frequency is 50/60Hz.
BulletPoint4 : Temperature control relay can select heating/cooling mode to monitor high/low temperature.
BulletPoint5 : Use 35mm rail installation, with small size, easy to carry and store, convenient to use and with good performance.
ExternallyAssignedProductIdentifier1 : 0769954490212
ExternallyAssignedProductIdentifier2 : 769954490212
IncludedComponents : No
ItemName : Temperature Controller, LN 2.5kV Thermostat with Probe for Temp Control for Controller for Engineering
ItemPackageDimensions_Height : 2 centimeters
ItemPackageDimensions_Length : 19 centimeters
ItemPackageDimensions_Width : 16 centimeters
ItemTypeKeyword : temperature-controllers
Manufacturer : Sonew
ModelName : Sonew14pnbc7g5a
ModelNumber : Sonew14pnbc7g5a
NumberOfItems : 1
PartNumber : Sonew14pnbc7g5a
ProductDescription : 1. Temperature control relay can select heating/cooling mode to monitor high/low temperature.
2. The working status is indicated by the LED indicator, the power indicator is green, and the output relay indicator is red.
3. Working power supply voltage AC/DC 24V‑240V, rated power supply frequency is 50/60Hz.
4. The maximum power consumption is 2VA, and the allowable fluctuation range of the power supply is -15%~+10%.
5. Use 35mm rail installation, with small size, easy to carry and store, convenient to use and with good performance.

Specification:
Item Type: Temperature Control Relay
Function: Monitor high/low temperature
Power Terminal: L-N
Rated Power Supply Voltage: AC/DC 24V-240V
Rated Power Frequency: 50/60Hz
Rated Impulse Withstand Voltage: 2.5kV
Rated Insulation Voltage: 250V
Power Consumption: Maximum 2VA
Power Supply Allowable Fluctuation Range: -15%~+10%
Temperature Adjustment Range: -15℃ to +45℃
Temperature Adjustment Hysteresis Value: 0.5℃ to 5°℃
Working Mode: Heating-cooling-on and off can be set
Power Indicator: Green LED
Output Parameters: 1xSPST 16A/AC1 250VAC/24VDC
Minimum Switching Power: 500mW
Output Relay Indication: Red LED
Mechanical Life: 1x10000000
Electrical Life (resistive Load): 1x100000
Working Environment Temperature: -20℃ ~+55℃
Storage and Transportation Environment Temperature: -35℃~+75℃
Installation Method: Approx. 35mm / 1.4in rail installation
Level: IP20
Installation Location: Any
Installation Altitude: Pollution Degree: 2
Wiring Capacity: 1x2.5mm² or 2x1.5mm² 0.8Nm

packing list:
1 x Temperature Control Relay
1 x Probe
1 x User Manual
ProductSiteLaunchDate : 2024-10-08T12:48:13.201Z
UnspscCode : 41112209
