Specification
AgeRangeDescription : Adult
Brand : YJINGRUI
BulletPoint1 : This belt tension meter tension tester V type triangle belt tester
BulletPoint2 : Installation Essentials (1) confirm whether the center of the spring strip and the center of the sliding center are aligned. If deviations, please make adjustments. (2) The place where the number is engraved on the spring bar of the measuring gauge is on the right side of the tensiometer body, and is located in the position where the body can be easily seen slightly outward. The center of the hook against the buckle center. (4) the spring bar is placed on the rack of the tension gauge
BulletPoint3 : Testing Essentials When the gauge is installed and measured, the steering wheel of the tensiometer should be loosened slowly, and letting go quickly is liable to produce large errors. The average value of the 3 Return and the numerical error printed on the gauge are within the normal range of less than 30N. If it is beyond 30N, it will need to be repaired and inspected.
BulletPoint4 : Be careful 1. do not remove the buckle from the spring bar. 2. do not smear any oil in the inspection department. 3. because it is a precision instrument, please use it carefully and keep it in good condition.
BulletPoint5 : Determination range :100-1000N (10-100kg)
Color : tensiometer+parallel ruler
Department : unisex
ImportDesignation : Imported
IncludedComponents : Protective Padded Short
ItemDisplayDimensions_Height : 0.59 inches
ItemDisplayDimensions_Length : 5.31 inches
ItemDisplayDimensions_Width : 5.31 inches
ItemDisplayWeight : 1.13 pounds
ItemName : YJINGRUI Belt Tension Meter 100-1000N Belt Tension Gauge Band Tension Tester Tension Force Measuring Measurement Tension Meter V-Type Triangle Belt Tester
ItemPackageDimensions_Height : 39.2 centimeters
ItemPackageDimensions_Length : 5 centimeters
ItemPackageDimensions_Width : 34.29 centimeters
ItemTypeKeyword : bike-spoke-tools
Manufacturer : YJINGRUI
Material : Resin
ModelName : Cienfy-03
ModelNumber : Cienfy-02
NumberOfBoxes : 1
PackageLevel : unit
PartNumber : WFF--71
Pattern : Solid
ProductDescription : speciality: 1.belt tension is correct, and simple measurement

2. using extension rod (optional), in small areas can also be tested.

3 .the use of the needle method, suitable for measuring the cover of the belt.

Operational attention 1.This belt tension meter belongs to the meter. When it is not used, please keep it in a special bag.

2.The instrument should not fall, hit, do not twist the hook, it can't slide properly, it can't be tested correctly.

3. The belt with a significantly lower tension， please do not test because it is possible to cause the twisting of the pointer and the damage of the internal gear.

4. The shell of the resin material shall not meet the oil of the mineral system and petroleum system. If it is encountered, it shall be cleaned immediately so that the measurement is not normal.

5. Please don't split and adjust the inside of the instrument.

6. Carry out the precision detection using the inspection gauge (selected piece) on a regular basis.

Operation method
1. return to "0" operation
The value of this belt tensiometer is expressed in pointer form, so the pointer must be returned to "0" position before measuring.

This operation, is to return to zero button (center protrusion button) to the arrow direction, the pointer to the dial back to zero position (red part range)

2. determination
1) Grasp the handle and steering wheel of the tensiometer tightly as shown in Figure 3, and hook the hook on the belt to be measured.
2) slow down， At this point, the internal springs make the belt bend, when the pointer represents the tension value of the belt.
3) in order to keep the pointer stable and accurate, the above 2 items should be repeated.
4) hold the tension gauge again and detach the gauge from the belt.
5) the value of the pointer is the tension value of the belt. (unit N)

ProductSiteLaunchDate : 2018-09-21T07:00:00.000Z
Size : Large
SportType : Skateboarding, snowboarding, skating, ice skating
StrapType : Adjustable
Style : impact-resistant
SupplierDeclaredDgHzRegulation : not_applicable
TargetAudience : Adult-Unisex
TargetGender : unisex
TeamName : Large
UnspscCode : 41110000
WarrantyDescription : 30 Days for return
