Specification
Brand : Generic
BulletPoint : 1PCS BESTEP 12V 2 Channel Relay Module High And Low Level Trigger For Auduino
BulletPoint1 : Load Current: 60A, 50-60 Hz
BulletPoint2 : Input Voltage: 80-250V AC
BulletPoint3 : Output Voltage: 24-480VAC
BulletPoint4 : No switching spark, fast switching speed, no noise, low electromagnetic interference
BulletPoint5 : Package Content: 2 x Solid State Module Relay, 4 x Mini Thermal Grease
Color : Black
ConnectorType : Plug-In
CurrentRating : 10 amps
ExternallyAssignedProductIdentifier : 7439453558746
IncludedComponents : 60AA
InputVoltage : 250 volts_of_alternating_current
ItemName : 1PCS BESTEP 12V 2 Channel Relay Module High and Low Level Trigger for Auduino
ItemPackageDimensions_Height : 3.2 centimeters
ItemPackageDimensions_Length : 5.8 centimeters
ItemPackageDimensions_Width : 4.4 centimeters
ItemPackageQuantity : 2
ItemTypeKeyword : solid-state-relays
Manufacturer : Generic
Material : lead
MaximumSwitchingCurrent : 10 amps
MaximumSwitchingVoltage : 12 volts
MeasurementSystem : Number
MeasurementSystem1 : Imperial
MeasurementSystem2 : Metric
ModelName : PUVDEVXK
ModelNumber : 60AA
MountingType : Plug In Mount
NumberOfItems : 1
OperatingVoltage : 480 volts_of_alternating_current
OperationMode : Automatic
PartNumber : SCDJ_UYN_10258
ProductDescription : Description:
The module uses genuine quality relay, normal open interface maximum load: AC 250V/10A, DC 30V/10A.
The chip optocoupler isolation, strong driving ability, stable performance, trigger current 5mA.
Working voltage is 12V.
Each channel of the module can be set up by high jumper or low level trigger.
Fault tolerant design, even if the control line is broken, the relay will not act.
Power indicator (green), 2 relay status indicator (red).
The interface design is humanized, all interfaces can be directly connected through the terminals, so it is very convenient.
Module size: 50mm x 42mm x 18.5mm (length x width x height).
There are 4 fixed bolt holes, holes 3.1mm, spacing 67mm x 44.5mm.
Module interface:
1, DC+: Connect the power positive pole (voltage according to relay 12V).
2, DC-: Connect the power negative pole.
3, IN1-IN2: According to the setting of each way, the corresponding relay-operating can be controlled by high or low level.
Relay output: there is a 6 wire interface, all interfaces can be directly connected to lead to facilitate user use.
1, NO1--NO2: Relay normal open, the relay suspends before pulling in, and then short-connect with the COM.
2, COM1--COM2: Relay common interface
3, NC1--NC2: Relay normal close, short connected with COM before pulling inand suspended after pulling in.
High and low level trigger option:

1. S1-S2 is the high level trigger selection of relay 1 Channel -2 Channel.
2. When COM is short connected with LOW, the corresponding relay is LOW level trigger, while when COM is short connected with high end is high level trigger.
Package Included:


1 x 2
Channel
5V Relay Module
ProductSiteLaunchDate : 2023-05-06T13:04:47.847Z
Size : JW1FSN-DC24V
SpecificationMet : CE
SupplierDeclaredDgHzRegulation : not_applicable
SupplierDeclaredHasProductIdentifierExemption : 1
UnitCount : 1
UnspscCode : 39122300
Wattage : 4400 watts
