Product Information
Editorial Review
Specification * Connector: - 1 x USB 3.1 Type-A female - 1 x eSATA (7 pin; Data) Female * Chipset: ASMedia ASM2142 + ASM1351 * One 10Gbps USB3.1 port and one 6Gbps External eSATA III port PCI Express 3.0 x4 Lane Host Adapter Card powered by ASM2142 with PCIe Gen3 x2 Lane performance. * Low Profile PCIe Form Factor board * Compliant with PCI Express Specification 3.0 * Include both Low Profile and Regular Size PCIe brackets * Require an empty PCIe 3.0 x4 or x8 or x16 slot in computer for USB3.1 full performance * Fully RoHS compliant 10Gbps Gen2 USB 3.1 * Compliant with USB 3.1 Spec. Rev. 1.0, Intel xHCI Spec. 1.1. * Compliant with USB Attached SCSI Protocol (UASP) Specification 1.0. * Support USB 3.1, 3.0, 2.0, and 1.1 devices. * Software: - No driver installation is required on Mac OS X 10.9 to 10.10, and 10.12 to 10.13 (NOTE: does NOT work on OS X 10.11), Win10/8.1/8, Server 2012, and Linux 2.6.31 and later. The OS native built-in drivers feature UASP. - The ASMedia driver for 32/64 bit Windows 7/Vista, and Server 2008/2003 is available from our website. (ASMedia driver doesn't support UASP) * Data transfer rate: - USB 3.1 Gen2 up to 10 Gbps * Power: - Support up to 2A/5V on USB-A downstream port. 6Gbps Serial ATA 3.0 * Fully compliant with Serial ATA specifications 3.0 transfer rate of 6Gbps * Supports SATA I & SATA II & SATA III HDD, SSD, Optical Drive and Blu-Ray Drive * Supports ATA and ATAPI commands * Supports SATA Hot-plug and Native Command Queuing (NCQ) * No SATA ODD and No Port Multiplier support * No additional driver required. Work with built-in native AHCI drivers on most Operating Systems. Package Contents * Ableconn 1-port USB 3.1 & 1-port eSATA PCIe x4 Card * One low profile PCIe bracket
Features
1) One 10Gbps USB3.1 port and one 6Gbps External eSATA III port PCI Express 3.0 x4 Lane Host Adapter
2) Low Profile board. Include both Low Profile and Regular Size PCIe brackets. PCIe x4 card fits in any PCIe 2.0 or PCIe 3.0 x4 or x8 or x16 slot.
3) Support up to 2A/5V on USB-A downstream port.
4) No driver installation is required on Mac OS X 10.9 to 10.10, and 10.12 Sierra (NOTE: does NOT work on OS X 10.11), Win10, 8.1, 8, and Server 2012. Driver download is available for 32/64 bit Windows 7/Vista, and Windows Server 2008/2003. Note: UASP featue is only available with Microsoft and OS X built-in drivers. Currently, the ASMedia driver does not have UASP feature.
5) Built with ASMedia ASM2142 with PCIe Gen3 x2 Lane performance. Fully RoHS compliant. Made in Taiwan.
Specification
Binding : Electronics
Brand : Ableconn
Color : 1x USB-A + 1x eSATA
Label : Ableconn
Manufacturer : Ableconn
Model : PU31A-ESA
PackageDimensions_Weight : 0.21 pounds
PackageDimensions : L:5.60 X W:4.00 X H:1.60
ProductGroup : PC Accessory
ProductTypeName : COMPUTER_ADD_ON
Publisher : Ableconn
Studio : Ableconn
Title : Ableconn PU31A-ESA 1-Port USB 3.1 10 Gbps Type-A & 1-Port eSATA III 6 Gbps PCI Express (PCIe) x4 Host Adapter Card
Specification * Connector: - 1 x USB 3.1 Type-A female - 1 x eSATA (7 pin; Data) Female * Chipset: ASMedia ASM2142 + ASM1351 * One 10Gbps USB3.1 port and one 6Gbps External eSATA III port PCI Express 3.0 x4 Lane Host Adapter Card powered by ASM2142 with PCIe Gen3 x2 Lane performance. * Low Profile PCIe Form Factor board * Compliant with PCI Express Specification 3.0 * Include both Low Profile and Regular Size PCIe brackets * Require an empty PCIe 3.0 x4 or x8 or x16 slot in computer for USB3.1 full performance * Fully RoHS compliant 10Gbps Gen2 USB 3.1 * Compliant with USB 3.1 Spec. Rev. 1.0, Intel xHCI Spec. 1.1. * Compliant with USB Attached SCSI Protocol (UASP) Specification 1.0. * Support USB 3.1, 3.0, 2.0, and 1.1 devices. * Software: - No driver installation is required on Mac OS X 10.9 to 10.10, and 10.12 to 10.13 (NOTE: does NOT work on OS X 10.11), Win10/8.1/8, Server 2012, and Linux 2.6.31 and later. The OS native built-in drivers feature UASP. - The ASMedia driver for 32/64 bit Windows 7/Vista, and Server 2008/2003 is available from our website. (ASMedia driver doesn't support UASP) * Data transfer rate: - USB 3.1 Gen2 up to 10 Gbps * Power: - Support up to 2A/5V on USB-A downstream port. 6Gbps Serial ATA 3.0 * Fully compliant with Serial ATA specifications 3.0 transfer rate of 6Gbps * Supports SATA I & SATA II & SATA III HDD, SSD, Optical Drive and Blu-Ray Drive * Supports ATA and ATAPI commands * Supports SATA Hot-plug and Native Command Queuing (NCQ) * No SATA ODD and No Port Multiplier support * No additional driver required. Work with built-in native AHCI drivers on most Operating Systems. Package Contents * Ableconn 1-port USB 3.1 & 1-port eSATA PCIe x4 Card * One low profile PCIe bracket
