Specification
Brand : AmpFlow
BulletPoint1 : Gearhead measures 6 x 3 x 2 inches. The motor is 5.8 inches long. The total weight is 9.4 pounds.
BulletPoint2 : No-load Speed: 780 RPM at 12 volts; Can be used with voltages ranging from 6V to 18VDC
BulletPoint3 : Maximum power: 1200 watts (1.6 horsepower); Maximum stall torque: 57 Nm (500 In-Lbs.)
BulletPoint4 : Peak efficiency at 12V is at 48 amps and 700 RPM
BulletPoint5 : Power and torque at peak efficiency: 480 watts (0.6 horsepower) and 6.6 Nm (58 In-Lbs.)
ExternallyAssignedProductIdentifier : 8719735012616
ExternallyAssignedProductIdentifier1 : 677355322226
ExternallyAssignedProductIdentifier2 : 0677355322226
Horsepower : 1200 watts
IncludedComponents : One motor
ItemName : AmpFlow E30-400-12-G Electric Gearmotor, 6V, 12V or 18 VDC, 780 RPM
ItemPackageDimensions_Height : 31.1 centimeters
ItemPackageDimensions_Length : 12 centimeters
ItemPackageDimensions_Width : 21.3 centimeters
ItemPackageQuantity : 1
ItemTypeKeyword : permanent-magnet-motors
Manufacturer : Powerhouse Engineering Inc.
Material : Aluminum
ModelName : gearhead,gearmotor
ModelNumber : E30-400-12-G
NumberOfItems : 1
PackageLevel : unit
PartNumber : E30-400-12-G
ProductDescription :

Specifications:

Model: 31ZY
Outer diameter: 31mm / 1.22in
Shaft length: 19mm / 0.75in
Shaft diameter: 3mm / 0.12in
Type(Optional): 6V 4000rpm,12V 4000rpm,12V 8000rpm, 24V 3500rpm, 24V 5000rpm, 24V 8000rpm

Weight:165g

Wiring:

CW: red: "+", black: "-"

CWW: red: "-", black: "+"

Working voltage V(Optional) 6V 12V 12V 24V 24V 24V

No-load current mA ≤180 ≤350 ≤110 ≤200 ≤200
≤41
No-load speed  rpm 4000 8000 4000 5000 8000 3500
Rated moment of force gf.cm 100 200 100 200 200 150
Rated speed rpm 3200 6500 3200 4000 6600 2500
Rated current A ≤0.8 ≤1.6 ≤0.5 ≤0.6 ≤1.0 ≤0.3
Locked-rotor moment of force gf.cm ≥500 ≥1000 ≥600 ≥850 ≥1200 ≤400
Locked-rotor current A ≤3.3 ≤6.5 ≤2.3 ≤2.0 ≤4.4 ≤0.8

Package includes:

1 x Motor

ProductSiteLaunchDate : 2020-04-16T21:50:25.065Z
Speed : 780 rpm
SupplierDeclaredDgHzRegulation : not_applicable
UnspscCode : 26101200
Voltage : 12 volts
Voltage1 : 380 volts
Voltage2 : 220 volts
