Specification
Brand : Deeoee
BulletPoint : Digital Oscilloscope DIY Kit 2.4 "tft DIY Parts for Oscilloscope Making Electronic Diagnostic-tool Learning Set
BulletPoint1 : 30/60/80/100MHz maximum sine output frequency
BulletPoint2 : 2CH analog channels, 16CH digital channels, 500MSa/s
BulletPoint3 : Support AM, FM, PM, ASK, PSK and PWM modulations. 16 channel digital output, together with the analog channel can rebuild the more mixed signals in daily practice
BulletPoint4 : Max. 64M arbitrary waveform memory depth, 80M frequency counter
BulletPoint5 : Please allow 2 - 3 weeks lead time for new product to arrive. Comes with a one year warranty from the manufacturer.
ExternallyAssignedProductIdentifier : 4862440104573
ItemName : Digital Oscilloscope DIY Kit 2.4 "tft DIY Parts for Oscilloscope Making Electronic Diagnostic-Tool Learning Set
ItemTypeKeyword : science-lab-oscilloscopes
Manufacturer : Deeoee
NumberOfItems : 1
PartNumber : CXXMODULE-11115
ProductDescription :
Features:
Training for electronic production , complete detailed descriptive information ,
including schematics , production guidance , instructions ,
troubleshooting methods , etc., making a high success rate .
Component species diversity for students to identify elements ,
inline elements welding, soldering SMD components training.
Students can get in at the same time making a practical tool
for audio, video synchronization , low-frequency switching power supply ,
infrared receiver transmitter signal waveform and many other occasions,
effectively observed and measured , increased interest in learning, improve learning outcomes .
Kits using ARM Cortex-M3 processor (STM32F103C8),
and includes a 2.4 -inch color TFT display can be used as test ARM development board .
Available source , the ability of a friend can be secondary development kit based on ,
for example, it can be changed to Millivoltmeter , data loggers , and so on .
Circuit is simple , reliable , inexpensive
Performance
Maximum real-time sampling rate : 1Msps
Accuracy : 12Bit
Sampling buffer depth : 1024 bytes
Analog bandwidth : 0 - 200KHz
Vertical Sensitivity : 10mV / Div - 5V / Div ( 1-2-5 progressive manner )
Adjustable vertical displacement , and with instructions
Input impedance : 1MΩ
Maximum input voltage : 50Vpp (1: 1 probe ), 400Vpp (10: 1 probe )
Coupling modes include DC / AC / GND
The horizontal time base range : 10μs / Div - 50s / Div ( 1-2-5 progressive manner )
With automatic, regular and one-shot mode , easy to capture the moment waveform
Available rising or falling edge trigger
Adjustable trigger level position , and with instructions
Observable trigger waveform before ( negative delay )
Can freeze at any time waveform display (HOLD function )
Comes 1Hz /3.3V square wave test signal source
Package included:
1PCS x Digital Oscilloscope+ Probe Unsold
ProductSiteLaunchDate : 2021-06-26T18:41:19.513Z
Style : SAG1002
UnspscCode : 39120000
