Specification
Brand : Aexit
BulletPoint : MODEL NUMBER: XTCE025C10TD - H2522
BulletPoint1 : Product Name:AC Contactor Model Number: CJX2-1810; Rated Coil Voltage: 220-230VAC 50Hz/220-240VAC,
BulletPoint2 : 60HZ;Rated Operating Current(Ie) :18AAC-3 V;Rated Operational Current(Ie): A; Controled Power(Pe): KW
BulletPoint3 : Rated Insulation Voltage(Ui):690V;Conventional Thermal Current(Ith):32A;Number of Contact:3P+NO
BulletPoint4 : Mounting Size:35x50mm/1.4"x2"(W*L);Overall Size(Approx.):80x71x45mm/3.1''x 2.8''x1.8''(L*W*T);
BulletPoint5 : Material:Plastic Metal Main Color: Black Net Weight: 346g;Package Content: 1xAC Contactor
CircuitBreakerType : Standard
CurrentRating : 18 amps
ExternallyAssignedProductIdentifier1 : 0653958817666
ExternallyAssignedProductIdentifier2 : 653958817666
ItemName : Aexit CJX2-1810 AC Circuit Breakers Contactor 18A 3 Poles One NO 220-230VAC Miniature Circuit Breakers 50Hz Coil
ItemPackageDimensions_Height : 2 inches
ItemPackageDimensions_Length : 2 inches
ItemPackageDimensions_Width : 2 inches
ItemPackageQuantity : 1
ItemTypeKeyword : motor-contactors
Manufacturer : Aexit
Material : copper
Material1 : Plastic
Material2 : Metal
ModelNumber : modle
MountingType : DIN Rail Mount
NumberOfPoles : 3
PartNumber : f190412ae002301
ProductDescription : Modular design allows contactors Put onto DIN rail or mount directly to a panel with screws. Three pole switching (main contacts) with single integral auxiliary contacts design. CJX2 series AC Contactor is suitable for using in the circuits up to the rated voltage 690V AC, 50Hz or 60Hz, for long distance making, breaking, frequently starting controlling the AC motor. With the thermal relay, it is combined into the electromagnetic for protecting the circuit in which overload operation may occur. Low power consumption, light weight, long service life, reliable. The Rated Voltage of Coil is AC 220V, please pay attention to the voltage to make sure the item can work successfully.

ProductSiteLaunchDate : 2018-11-26T06:17:09.574Z
SupplierDeclaredDgHzRegulation : unknown
UnitCount : 1
UnspscCode : 39121600
Voltage : 690 volts
