Product Information
Editorial Review
320Ã--480, 3.5 inch Touch Screen IPS TFT LCD Designed for Raspberry Pi Features 320Ã--480 resolution Resistive touch control Supports any revision of Raspberry Pi (directly-pluggable) Drivers provided (works with your own Raspbian/Ubuntu directly) IPS technology, high quality and perfect displaying from very wide viewing angle Size perfectly fits the Pi High quality immersion gold surface plating Supports Raspbian system, enables your system to: o Take photos by touching (up to 17 camera modes) o Support software keyboard (system interaction without keyboard/mouse) 3.5inch RPi LCD (A) and 3.5inch RPi LCD (B) are hardware compatible with each other (uses different driver), and can be mutually substituted in most cases. (A) for low cost ver. while (B) for IPS ver. with better displaying. Key Parameters LCD Type: IPS LCD Interface: SPI Touch Screen Type: Resistive Touch Screen Controller: XPT2046 Colors: 65536 Backlight: LED Resolution:320*480(Pixel) Aspect Ratio: 8:5 Power Consumption: TBD Backlight Current: TBD Operating Temp. (Degree): TBD
Features
1) 320x480 resolution;Supports any revision of Raspberry Pi (directly-pluggable)
2) Drivers provided (works with your own Raspbian/Ubuntu directly)
3) IPS technology, high quality and perfect displaying from very wide viewing angle
4) Size perfectly fits the Pi;High quality immersion gold surface plating
5) 3.5inch RPi LCD (A) and 3.5inch RPi LCD (B) are hardware compatible with each other (uses different driver), and can be mutually substituted in most cases. (A) for low cost ver. while (B) for IPS ver. with better displaying.
Specification
Binding : Electronics
Brand : Waveshare -LCD
EAN : 0614961950344
Label : Waveshare
Manufacturer : Waveshare
Model : 3.5inch RPi LCD (B)
PackageDimensions_Weight : 0.18 pounds
PackageDimensions : L:5.50 X W:5.20 X H:1.50
ProductGroup : Office Product
ProductTypeName : COMPUTER_COMPONENT
Publisher : Waveshare
Size : 3.5inch RPi LCD (B)
Studio : Waveshare
Title : Waveshare 3.5inch RPi LCD (B) 320480 Resoution Touch Screen IPS TFT Display Designed for any Revision of Raspberry Pi Directly-pluggable Better Displaying
320Ã--480, 3.5 inch Touch Screen IPS TFT LCD Designed for Raspberry Pi Features 320Ã--480 resolution Resistive touch control Supports any revision of Raspberry Pi (directly-pluggable) Drivers provided (works with your own Raspbian/Ubuntu directly) IPS technology, high quality and perfect displaying from very wide viewing angle Size perfectly fits the Pi High quality immersion gold surface plating Supports Raspbian system, enables your system to: o Take photos by touching (up to 17 camera modes) o Support software keyboard (system interaction without keyboard/mouse) 3.5inch RPi LCD (A) and 3.5inch RPi LCD (B) are hardware compatible with each other (uses different driver), and can be mutually substituted in most cases. (A) for low cost ver. while (B) for IPS ver. with better displaying. Key Parameters LCD Type: IPS LCD Interface: SPI Touch Screen Type: Resistive Touch Screen Controller: XPT2046 Colors: 65536 Backlight: LED Resolution:320*480(Pixel) Aspect Ratio: 8:5 Power Consumption: TBD Backlight Current: TBD Operating Temp. (Degree): TBD
Features
1) 320x480 resolution;Supports any revision of Raspberry Pi (directly-pluggable)
2) Drivers provided (works with your own Raspbian/Ubuntu directly)
3) IPS technology, high quality and perfect displaying from very wide viewing angle
4) Size perfectly fits the Pi;High quality immersion gold surface plating
5) 3.5inch RPi LCD (A) and 3.5inch RPi LCD (B) are hardware compatible with each other (uses different driver), and can be mutually substituted in most cases. (A) for low cost ver. while (B) for IPS ver. with better displaying.
Specification
Binding : Electronics
Brand : Waveshare -LCD
EAN : 0614961950344
Label : Waveshare
Manufacturer : Waveshare
Model : 3.5inch RPi LCD (B)
PackageDimensions_Weight : 0.18 pounds
PackageDimensions : L:5.50 X W:5.20 X H:1.50
ProductGroup : Office Product
ProductTypeName : COMPUTER_COMPONENT
Publisher : Waveshare
Size : 3.5inch RPi LCD (B)
Studio : Waveshare
Title : Waveshare 3.5inch RPi LCD (B) 320480 Resoution Touch Screen IPS TFT Display Designed for any Revision of Raspberry Pi Directly-pluggable Better Displaying
