Specification Brand : HOJILA BulletPoint : Yw-552m Portable Integrated Design Environment Light Lux Meter Illuminance Meter BulletPoint1 : Seven parameters can be measured: 365nm UV rejection rate, 940nm/1400nm/full infrared rejection rates, visible light transmittance,TSER and SHGC total solar transmittance BulletPoint2 : The solar film tester has large color LCD display interface which directly display the IR and UV rejection rate BulletPoint3 : The parallel light path design is used to test large thickness glass with accurate data BulletPoint4 : The spectrum transmission meter has a real-time dynamic self-calibration function, which is automatically calibrated after power-on BulletPoint5 : The SHGC transmission meter has Type-C interface which can be directly connected to mobile power BulletPoint6 : A support rod is provided to tilt the instrument for easy reading BulletPoint7 : Air Transportation : Standard timeframe is approximately 7-13 days. ExternallyAssignedProductIdentifier : 5780414231270 IncludedComponents : Spectrum Transmission Meter ItemName : HOJILA LS182 Spectrum Transmission Meter, Window Film Transmission Meter, UV IR Rejection Meter ItemPackageDimensions_Height : 2.1 inches ItemPackageDimensions_Length : 3.5 inches ItemPackageDimensions_Width : 7.2 inches ItemTypeKeyword : science-lab-photometers-and-light-meters Manufacturer : HOJILA ModelName : LUCKDANOon0fgtx3hm ModelNumber : LS162A NumberOfItems : 1 PartNumber : LS182 ProductDescription : LS182 spectrum transmission meter is a device that can test the SHGC value (that is, the total solar transmittance, also called the solar heat gain coefficient), 950nm, 1400nm, TSER and Full IR rejection rate, 365nm ultraviolet rejection rate and 380nm-760nm visible light transmittance. The testing principle of the LS182 spectrum transmission meter is to use an ultraviolet light source, a visible light source and an infrared light source to illuminate the measured transparent materials. The sensor detects the incident light intensity of the light source and the light intensity passing through the materials. The ratio is equals to light transmittance which is shown in percentage. For most solar films, the visible light is marked with the transmittance index and the infrared and ultraviolet rays are marked with the rejection rate index.
The LS182 spectrum transmission meter has a wide range of applications. Due to its parallel light path and wide test slot, it can be used in the solar film industry to test solar films, laminated glass, etc., as well as various large thickness materials. The instrument is suitable for using on solar film performance exhibition, production, quality inspection, inspection and other occasions.
Specifications: UV peak wavelength : 365nm IR peak wavelength: 940nm, 1400nm, Full IR , TSER and SHGC Visible light: 380-760nm (conform to CIE photopic luminosity function) Resolution: 0.1% Measurement accuracy: ± 2% (colorless and uniform transparent material) Test card slot: 47mm×91mm (W*H) Weight: about 590g Dimension: 216mm × 134mm × 29mm (L*H*W) Power supply: 5V DC/1A (Type-C)
Packing List: 1 x LS182 spectrum transmission meter 1 x DC5V Adapter 1 x User Manual 1 x Certificate / warranty card 1 x Support pillar
