Specification
Brand : CIXIFM
BulletPoint1 : 24 power supply, thread G1/2, contact material peek, stainless steel 304 housing,-20℃～80℃
BulletPoint2 : The electrode integrated in the sensor probe forms a capacitor with the surrounding environment using frequency sweep technology, and its capacitance value depends on the dielectric constant of the medium. The capacitor and the inductor coil in the sensor circuit together form a resonant circuit. Based on the measured resonant frequency and the adjustable switch action range, the switch signal can be triggered.
BulletPoint3 : High-quality workmanship, precise measurement
BulletPoint4 : ❶ When installing the product, the outer shell needs to be connected to the metal tank to ensure the stability of the measurement; ❷ For low dielectric constant materials, the sensitivity should be lowered during debugging to ensure the accuracy of the measurement, and the operator can be used for calibration;
BulletPoint5 : ❸ For measuring different materials, the material with low dielectric constant is used as the calibration standard to meet the measurement of high dielectric constant materials; ❹ When encountering sticky materials, the sensitivity can be lowered to ensure that there is no interference from the coating during measurement; ❺ If delay/high and low position switching/hysteresis value adjustment is required, please use our company's dedicated operator to modify it.
Color : #711
ExternallyAssignedProductIdentifier : 7704700066771
IncludedComponents : Switch
ItemDisplayWeight : 0.07 pounds
ItemName : CIXIFM micro capacitance level switch frequency sweeping scanning level switch 24V thread G1/2 SS304 contact material peek NPN
ItemPackageDimensions_Height : 7 centimeters
ItemPackageDimensions_Length : 32 centimeters
ItemPackageDimensions_Width : 13 centimeters
ItemPackageQuantity : 1
ItemTypeKeyword : levels
Manufacturer : Shanghai Cixi Instrument Co., Ltd.
Material : PVC
ModelName : capacitance level switch
ModelNumber : CX-SLS-NPN
NumberOfItems : 1
OperationMode : Manual
PartNumber : Mavaolrw97zc5ogp
PowerSourceType : dc
ProductDescription : CIXIFM capacitance level switch frequency sweeping level switch scanning level switch 24V, thread G1/2 SS304, contact material peek


Basic parameters

1. Housing material: SUS304
2. Wetted part(sensor)material: PTFK coating
3. Operating temperature: -20℃～80℃
4. Connection specification: G1/2"
5. Power supply: 16～24VDC
6. Power consumption: 1W
7. Output signal: NPN or PNP output

The electrode integrated in the sensor probe uses frequency sweep technology to form a capacitor with the surrounding environment, and its capacitance value depends on the dielectric constant of the medium. The capacitor and the inductor coil in the sensor circuit together form a resonant circuit. Based on the measured resonant frequency and the adjustable switch action range, the switch signal can be triggered.


High sensitivity:
When the probe just touches the material, press the calibration point with a special magnet, let it stand for about 3 seconds, see the red light flashing, remove the magnet, and when the red light stops flashing, the calibration is completed.

Medium sensitivity:
When the probe submerges half of the probe, press the calibration point with a special magnet, let it stand for about 3 seconds, see the red light flashing, remove the magnet, and when the red light stops flashing, the calibration is completed.

Low sensitivity:
When the probe completely submerges the probe, press the calibration point with a special magnet, let it stand for about 3 seconds, see the red light flashing, remove the magnet, and when the red light stops flashing, the calibration is completed.



ProductSiteLaunchDate : 2025-03-21T03:25:49.694Z
Size : 50.00X8.00X0.20CM
Style : NPN signal output
SupplierDeclaredDgHzRegulation : not_applicable
SupplierDeclaredHasProductIdentifierExemption : 1
UnitCount : 1
UnspscCode : 39122200
Voltage : 24 volts
