Specification
Brand : Dodoam
BulletPoint1 : Build to Last: This product uses high-quality Q235 steel and polishing and painting processes, making it wear-resistant, corrosion-resistant, rustproof, and has a long service life.
BulletPoint2 : Adjustable Design: You can adjust the lifting arm length at 3.61/4.35/5.09ft and angle at 0°/20°/40° and the crane height from 3.45-6.89ft to meet your different construction environments and usage needs. The 360° rotatable base also brings more convenience during the lifting process.
BulletPoint3 : Stable Structure: The large square base(9.45-in in length) with four screw-reinforced installation holes makes the product highly stable, so you don't have to worry about shaking or collapsing during the production process.
BulletPoint4 : User-friendly Design: The equipped remote control allows you to control the electric winch within a distance of 49.21ft, and it can also control the up and down directions (one is up, the other is down)greatly improving operation convenience.
BulletPoint5 : Strong Load-bearing Capacity: The maximum 1100 lbs load capacity of the truck-mounted crane and 3500 lbs load capacity of the electric winch allow you to use this product with confidence to lift heavy objects such as engines, tables, and shop equipment.
Color : Red
IncludedComponents : 1*Truck-Mounted Crane Hoist 1*Electric Winch 1*Remote Control Assembly All Accessories Required for Installation
ItemName : Dodoam Truck-Mounted Crane Hoist,1100 LB, with 12V Electric Winch, Pickup Truck Jib Cranes,Adjustable Boom Length, 360 Degree Swivel, Suitable for Construction, Forestry and Factory Lifting Goods
ItemPackageDimensions_Height : 7.3 inches
ItemPackageDimensions_Length : 31.9 inches
ItemPackageDimensions_Width : 13.6 inches
ItemTypeKeyword : jib-cranes
Manufacturer : Dodoam
ModelName : Truck-Mounted Crane Hoist
ModelNumber : AHIOGHUYI
NumberOfItems : 1
PartNumber : B55B6B0DB261
PowerSourceType : hand_powered
ProductDescription :

Details

Durable Hook: Made of alloy steel, it is durable and helps to hang goods without falling off easily.



Winch Rope: The 24.6ft wire rope can meet your basic needs without buying another one.



Steering Handle: It plays a turning function, allowing for convenient operation.



Wire Rope Limit Pin: It ensures that the steel wire rope does not exceed its maximum tension range to avoid accidents such as breakage of the steel wire rope due to exceeding its load-bearing capacity during movement.



Application

It is mounted on a truck to lift generators, engines, compressors, wood, shop equipment, etc. It is suitable for the construction industry, forestry industry, and more.



Specification

Material: Q235 Steel

Color: Orange

Surface Treatment: Polishing and Painting Processes

Assembly Required: Yes

Number of Items: 1

Electric Winch Voltage: 12V

Winch Rope Length: 7.5m/24.6ft

Battery Model: 1 * AA Battery(Included)

Electric Winch Capacity: 1587kg/3500lb

Lifting Arm Bearing Capacity: 100kg/220lb; 250kg/550lb; 500kg/1100lb

Cable Length: 1.3m/4.27ft

Remote Control Distance: 15m/49.21ft

Lifting Arm Height Adjustment Range: 0°-20°-40°

Lifting Arm Length Adjustment Range: 1.1m/3.61ft; 1.325m/4.35ft; 1.55m/5.09ft

Base Rotation Angle: 360 °

Gross Weight: 44kg/97lb

Net Weight: 40kg/88.18lb

Support Pole Height: 1.05m/3.45ft

Base Size: 24*24cm/9.45*9.45in

Installation Hole Diameter: 17mm/0.67in

Product Size(L&H): 1.14*1.05-2.1m/3.74*3.45-6.89ft

Package Size: 105*30*25cm/41.34*11.81*9.84in



Package Included

1*Truck-Mounted Crane Hoist

1*Electric Winch

1*Remote Control Assembly

All Accessories Required for Installation



Notes

1. Please read the label carefully before using it. Please stay away from the area around the wire rope and drum.

2. Please pull out the rope in the direction of the arrow. Please do not use it for overloaded lifting or moving personnel.

3. Please take a 10-minute break after 30 minutes of continuous work. Please turn off the power switch when not in use.

4. Please allow the slight color difference caused by the shooting light and the 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
