Brand : Hilitand
BulletPoint1 : [Easy Assembly] Featuring through-hole components, this generator is easy to assemble and debug, making diy projects enjoyable.
BulletPoint2 : [Versatile Application] Widely used by engineers, technicians, factories, and electronics enthusiasts for a variety of applications and projects.
BulletPoint3 : [Frequency Range Adjustable] The adjustable frequency range with five-digit resolution meets various needs with .
BulletPoint4 : [High Accuracy] This generator provides precise sine, , and square waves for accurate testing and analysis.
BulletPoint5 : [ Material] Constructed with pcb and abs materials, this generator ensures long-lasting performance.
ExternallyAssignedProductIdentifier : 7688540622666
ItemName : XR2206 Generator DIY Kit 5 Digit Resolution, High Accuracy, Adjustable Frequency Range, for Engineers, Technicians, Factories, DIY, Electronics Enthusiasts
ItemPackageDimensions_Height : 4 centimeters
ItemPackageDimensions_Length : 15 centimeters
ItemPackageDimensions_Width : 11 centimeters
ItemTypeKeyword : function-generators
Manufacturer : Hilitand
MetalType : other
ModelName : WALFRONT8yb743gc5n
ModelNumber : Hilitandpqscxh187i
PartNumber : Hilitandpqscxh187i
ProductDescription : Spec:

Item Type: Generator
Model: XR2206
Material: PCB+ABS
Input Voltage: 9-12V DC



Package List:
1 x Circuit Board
27 x Electronic Component
6 x Shell Parts
9 x Screw
5 x Nut
1 x Manual


How To Use:
Welding installation:
1. Components are based on the principle of low to high, that is, the first type of low welding components, such as capacitors, resistors, diodes, etc., are welded to the front panel
2. Welding IC sockets, terminal blocks, and finally power sockets, adjustable potentiometers
3. Use diagonal cutting pliers on the back to cut the pins as short as possible
Debugging steps:
1 After completing the soldering of the integrated circuit XR 2206, pay attention to the direction of the IC and insert the chip that may be damaged
2. Check whether the IC is correct, and correct it if necessary
3. Plug in the power supply, the power supply is a 5.5 x 2.1 port, and the inside is negative. For a power supply voltage of 9‑12V. The waveform may be unstable when it exceeds 12V
