Product Information
Specification
Brand : MeterTo
BulletPoint : Flow Control Unit
BulletPoint1 : Pipe Range:DN300~6000
BulletPoint2 : Temperature Range:-40~160
BulletPoint3 : Warranty : 1 year
BulletPoint4 : Stock：Yes
BulletPoint5 : Model number : TL-1-HT
Color : moderate grey
ExternallyAssignedProductIdentifier : 4549747241421
ExternallyAssignedProductIdentifier1 : 0666354850571
ExternallyAssignedProductIdentifier2 : 666354850571
IncludedComponents : No
ItemName : MeterTo TUF-2000H-TM-1-HT Handheld Digital Ultrasonic Flow Meter, High Temperature Clamp On: TM-1-HT, Measure Range: DN50-700mm, Temperature Range: -40°C ~ 160°C
ItemPackageDimensions_Height : 8.4 centimeters
ItemPackageDimensions_Length : 5.6 centimeters
ItemPackageDimensions_Width : 6.8 centimeters
ItemTypeKeyword : science-lab-flowmeters
Manufacturer : MeterTo
Material : TL-1-HT-JUNEE NI
ModelNumber : TH5B0073#G14
PartNumber : TH5B0073#G14
PowerSourceType : Handheld
ProductDescription :
Principle: transit-time ultrasonic flowmeter
Accuracy:over 1%-2%; Repeatability: over 0.2%
Display: 4 line x 16 character LCD with backlight
Dimension: 200*93*33cm: 390g
Operation: Support 16 key light touch keyboard and the Simulation keyboard software
Data interface: Insulate RS232 serial interface, upgrade the flew meter software by computer, support the MODBUS, etc.
Signal Output: 1 way OCT output
Pipe Material: Steel, Stainless steel, Cast iron, Copper, Cement pipe, PVC, Aluminum, Glass steel product, liner is allowed.
Straight length pipe: Transducer installation should be satisfied: upstream 10D, downstream 5D, 30D from the pump.
Type of Liquid: Water ; Ultra-pure liquids; Solvents and other liquids
Turbidity: under 10000ppm and less bubble
Flow rate: 0--±10m/s
Flow Direction: Measuring two (plus-minis) direction of flow rate
Working Environment: Temperature: Main Unit: -20--60℃;Humidity: Main Unit: 85% RH.
Power Supply: 3 AAA built-in Ni-MH batteries (for over 12 hours of operation), 100V-240V
ProductSiteLaunchDate : 2018-02-22T08:00:00.000Z
Size : Large
Style : Digital
