Flow Sensor Meter Digital Pipeline Water Flow High Performances DN20 Water Flow Brass Water Flow Switchs 1.5-50L/min Water Flows Control Sensor Liquid Flow Meter

Imported from USA | Ships in 10 working days

5% instant discount on non COD

1

₹ 6000/-

The price at cart2india.com is inclusive of custom duties, GST, freight forwarding and other charges.

Free Shipping across India. Powered by BlueDart

Product Information


Specification
Brand : KUAOXK
BulletPoint1 : 1. The screen can provide clear readings, and the internal accessories are made of stainless steel.
BulletPoint2 : 2. Plug and play, compact size, stable performance. Easy to replace and maintain internal components, suitable for output modules, sensors and remote transmitters.
BulletPoint3 : 3. LCD display: The LCD screen can display instantaneous flow and cumulative flow.
Color : One Color
ExternallyAssignedProductIdentifier : 7635668163960
ItemName : Flow Sensor Meter Digital Pipeline Water Flow High Performances DN20 Water Flow Brass Water Flow Switchs 1.5-50L/min Water Flows Control Sensor Liquid Flow Meter
ItemPackageDimensions_Height : 1 centimeters
ItemPackageDimensions_Length : 3 centimeters
ItemPackageDimensions_Width : 2 centimeters
ItemPackageQuantity : 1
ItemTypeKeyword : science-lab-flowmeters
Manufacturer : KUAOXK
Material : metal
MeasurementAccuracy : 1
ModelName : KUAOXK
ModelNumber : KUAOXK
NumberOfBoxes : 1
NumberOfItems : 1
PartNumber : KUAOXK
PowerSourceType : AC
ProductDescription : 1. Zero function, instantaneous flow and cumulative flow readings on the display screen, the readings are intuitive and clear, and highly reliable
2. Strong and durable, long service life, small size, accurate measurement and simple operation.
3. Internal thread, easy to install, tight sealing, no leakage.
Features:
Good sealing effect, easy installation.
Brass material, durable, high temperature resistance.
When this product is connected to 50W load, intermediate material must be added, otherwise it cannot be used.
Working method: When there is water in the water flow switch, and the water flow speed is 1.5L/min, the magnetism in the water flow switch will receive water. The flow pushes the displacement, and the magnetic displacement drives the magnetic source to produce a magnetic control effect, so that the water flow switch outputs the "on" signal. The signal is input to the device control system, and the control system realizes the control function. When the water flow is less than the starting flow, the water flow switch outputs an "off" signal. The control system produces the same reverse control.
Specifications:
Material: Brass
Thread :DN20
Inner diameter :18mm, outer diameter :26mm
Thread :15 mm
Switching current :0.5A
Load current :0.5A
Contact resistance :100mg
Load power :50W
Load voltage :220VDC
Minimum breakdown voltage :220VDC
Starting water flow rate :1.5L/MIN
Working water flow range :1.5-50L/MIN
Starting water pressure :0.1Mpa
Water pressure :1.75Mpa
Operating temperature :1~120℃
Applicable temperature :-20~150℃
Response time :0.2S
Release time :0.2S
Size: about 6.2 x3.3 x3cm / 2.44 x1.30 x1.18 in
The package includes:
1 meter counter
Attention:
Please allow 1-2cm error due to manual measurement, please make sure you do not mind before ordering.
Due to differences between different monitors, the picture
ProductSiteLaunchDate : 2024-08-03T01:45:28.625Z
Size : One Size
UnitCount : 1
