Product Information
Editorial Review
Zero timing firmware for roar SPORTMAN races and other fair races. World's smallest footprint & lightweight ESC ever. "23.5G" programming/upgrading/ data reading wirelessly: integrated data logger can record the maximum temperature of ESC and motor as well as the maximum RPM. Built-in boost BEC with a maximum output of 6A and voltage adjustable between 6V and 7.4V for usage with high voltage servos. Separate program/fan port is able to power an external fan for maximize cooling performance or connect a LCD program box or Wi-Fi module to the ESC. With HobbyWing Wi-Fi express module, users are able to program parameters, upgrade firmware and check relevant data during the event using either the iPhone or Android devices. New brakes and throttle functions: 100 levels of brag brake, 50 levels of initial brake force, 9 levels of maximum brake force, 20 levels of brake Rate, and 30 levels of throttle Rate. Adjustable brake mode, PWM and brake frequencies and for different competitions and control feel. Adjustable turbo timing & boost timing for different applications. Multiple protections: low-voltage cutoff protection, ESC and motor thermal protection, and fail safe (throttle signal loss protection). data logging for recording the maximum ESC/motor temperature, motor speed/RPM, and others in real time.
Features
1) MOTOR LIMIT: Motor Supported Sensored and sensorless brushless motors, Suitable Motor 3650 Motors T10.5T
2) Application stock class of 1/12 - /1/10; current Continuous: 80A, burst: 380A; battery 3-4S NiMH, 1S LiPo; cooling fan 5V - 7.4V, (20x20x8mm)
3) Wires 14awg-200mm; size 31.6 x 25.8 x 16.2mm; weight** 23.5G**; ** weight is W/O wires, cooling fan
4) For 7-9 Cells NiMH/nicd or 3S LiPo, the standard cooling fan must be changed to 12V high voltage fan.
Specification
Binding : Toy
Brand : Hobbywing
EAN : 0088718508438
Label : HRP Distribution, us toys
LegalDisclaimer : HOBBYWING official manufacturer warranty - Note: Hong Kong, Chinese stores are not HOBBYWING authorized store in North America. Deems items non-warranty If typographical errors appear on or within our website, we sincerely apologize and appreciate all help in identifying such errors so as to correct them as quickly as possible. Nonetheless, HOBBYWING North America cannot be held responsible for typographical errors and assumes no responsibility for said errors. High power system for RC model can be very dangerous, so please read this manual carefully. HOBBYWING North America has no control over the correct use, installation, application, or maintenance of our products, no liability shall be assumed nor accepted for any damages, losses or costs resulting from the use of the product. Any claims arising from the operating, failure of malfunctioning etc. will be denied. We assume no liability for personal injury, consequential damages resulting from our product or our workmanship. As far as is legally permitted, the obligation to compensation is limited to the invoice amount of the affected product.
Manufacturer : HRP Distribution, us toys
ManufacturerMaximumAge : 16.00 years
Model : HWI30112751
PackageDimensions_Weight : 0.40 pounds
PackageDimensions : L:5.25 X W:3.50 X H:2.19
ProductGroup : Hobby
ProductTypeName : TOYS_AND_GAMES
Publisher : HRP Distribution, us toys
ReleaseDate : 2017-01-01
Studio : HRP Distribution, us toys
Title : HobbyWing Electronic 30112751 Xr10 Pro Stock Spec 1S Sensored Brushless ESC Speed Control
