Pomona 3863-0 Polycarbonate Triple Mounting Base for Standard Binding Post, Black (Pack of 10)

Customer rating 4.4 stars

Imported from USA | Ships in 10 working days

5% additional discount on UPI | Cash On Delivery available

1

₹11880 -36% ₹7600/-

The price at cart2india.com is inclusive of custom duties, GST, freight forwarding and other charges.

Free Shipping across India. Powered by BlueDart.
EMI and GST Invoice available.

Product Information


Specification
Brand : Pomona
BulletPoint1 : Black polycarbonate triple mounting base for standard binding post
BulletPoint2 : Pack of 10
BulletPoint3 : Wire specification: <4m㎡/11AWG, Cable specification: 15mm max, Panel cutout: 28.5mm, Item net weight: 3.58oz
BulletPoint4 : What's in the package: 1 plug + 1 socket with cap + 4 set of screws , Type: Circular Waterproof Docking Connectors
BulletPoint5 : Stable electrical performance, high strength and resistance to pressure, high temperature resistance, anti-explosion, anti-corrosive.
Color : Black
ExternallyAssignedProductIdentifier : 4872973117148
ExternallyAssignedProductIdentifier1 : 095969178440
ExternallyAssignedProductIdentifier2 : 0095969178440
IncludedComponents : Connector Housing, Contacts, Contact Release Tool
ItemName : Pomona 3863-0 Polycarbonate Triple Mounting Base for Standard Binding Post, Black (Pack of 10)
ItemPackageDimensions_Height : 1.43 inches
ItemPackageDimensions_Length : 7.12 inches
ItemPackageDimensions_Width : 5.97 inches
ItemPackageQuantity : 1
ItemTypeKeyword : electronic-component-cylindrical-connectors
Manufacturer : Pomona Electronics
Material : Polycarbonate
ModelNumber : 3863-0
NumberOfItems : 10
PartNumber : 3863-0
ProductDescription : SA28 IP67 Waterproof connector, 2 3 4 7 8 9 10 12 16 17 20 24 26PIN Aviation Connector
HIGH VOLTAGE POWER CABLE BULKHEAD AVIATION Square Panel Mount FEMALE PLUG MALE SOCKET

Model:
Square panel mount: SA2810/S*B, SA2813/P*B
Thread nuts panel mount: SA2810/S*B, SA2812/P*B
Cable to cable: SA2810/S*B, SA2811/P*B
2pin,3pin:
Rated Current (A): 50A
Contact diameter × number: Φ3.5x2 / Φ3.5x 3
Rated voltage (AC.V.): 500V
Withstanding Voltage (AC.V) 1 minute: 1500V
Contact resistance: 0.5mΩ
Wire specification: <10m㎡/7AWG

4pin, 7pin, 8pin, 10pin:
Rated Current (A): 25A
Contact diameter × number: Φ2.5x5 /Φ2.5x7 / Φ2.5x8 / Φ2.5x10
Rated voltage (AC.V.): 500V
Withstanding Voltage (AC.V) 1 minute: 1500V
Contact resistance: 1mΩ
Wire specification: <4m㎡/11AWG

9pin:
Rated Current (A): 25A, 5A
Contact diameter × number: Φ2.5x4, Φ1.0x5
Rated voltage (AC.V.): 500V
Withstanding Voltage (AC.V) 1 minute: 1500V
Contact resistance: 1mΩ, 5mΩ
Wire specification: <4m㎡/11AWG, <1.0m㎡/18AWG

12pin, 16pin, 17pin:
Rated Current (A): 10A
Contact diameter × number: Φ1.5x12 / Φ1.5x16 / Φ1.5x17
Rated voltage (AC.V.): 500V
Withstanding Voltage (AC.V) 1 minute: 1500V
Contact resistance: 2.5mΩ
Wire specification: <2.0m㎡/14AWG

20pin, 24pin, 26pin:
Rated Current (A): 5A
Contact diameter × number: Φ1.0x20 / Φ1.0x24 / Φ1.0x26
Rated voltage (AC.V.): 400V
Withstanding Voltage (AC.V) 1 minute: 1200V
Contact resistance: 5mΩ
Wire specification: <0.785m㎡/18AWG

Other details:
Coupling: Push-pull
Shell Materia: Anodized aluminium
Insert Material: PPS, max temperature 260°
Contact materia: Brass (gold-plated)
Termination: solder (2 to 10 pin crimp available)
Cable outer diameter range: 16mm max
Protection level: IP67
Durability: ≥50
ProductSiteLaunchDate : 2013-03-27T21:51:36.639Z
Size : 24 pin
Style : 6 Pin Gray Male Stamped
SupplierDeclaredDgHzRegulation : not_applicable
UnitCount : 10
UnspscCode : 41113700
