ATO 20 hp VFD, 20 hp (15 kW) variable frequency drive, converts 1-phase 240V to 3-phase 380V for AC motor speed control, to realize high precision and wide speed regulating range and high performance.
Specification:
Basics:
ModelGK3000-CS0150G
Capacity20 hp (15 kW)
Shipping weight18 kg
Dimension500*296*276 mm
I/O Feature:
Rated current32 A
Input voltage1 phase 220V AC
Input frequency50Hz/ 60Hz
Output voltage (Optional)3 phase AC 380V
Output frequency0.00~400.00Hz
Over load capacity150% of rated current for 1 minute, 180% of rated current for 3 seconds
Control Feature:
Control modeV/F control;
Sensorless vector control;
CommunicationRS485
Speed regulation1:100
Start torque150% of rating torque at 1 Hz
Speed control accuracy≤±0.5% of rating synchronous speed
Frequency precisionDigital setting: max frequency x± 0.01%;
Analog setting: max frequency x± 0.2%
Frequency resolutionAnalog setting: 0.1% of max frequency;
Digital setting: 0.01Hz
Torque boostAutomatic torque boost, manual torque boost 0.1%~30.0%
Interior PID controllerBe convenient to make closed-loop system
Automatic energy save runningOptimize V/F curve automatically based on the load to realize power save running
Automatic voltage regulation (AVR)Can keep constant output voltage when power source voltage varies.
Automatic current limitingLimit running current automatically to avoid frequent over-current which will cause trip
Environment:
Enclosure ratingIP 20
Temperature–10℃~ +40℃; VFD will be derated if ambient temperature exceed 40℃; each rise 1℃, the derate will be 5%
Humidity5%-95%, without condensation
Altitude≤1000m; VFD will be derated
