Specification
Brand : Raymarine
BulletPoint : 10040002
ExternallyAssignedProductIdentifier1 : 0012300290272
ExternallyAssignedProductIdentifier2 : 012300290272
ItemDisplayWeight : 7 pounds
ItemName : Raymarine ACU-400 Actuator Control Unit - Use Type 2 & 3 Hydraulic , Linear & Rotary Mechanical Drives
ItemPackageDimensions_Height : 11 inches
ItemPackageDimensions_Length : 13 inches
ItemPackageDimensions_Width : 13 inches
ItemPackageQuantity : 1
ItemTypeKeyword : boat-autopilots
Manufacturer : Raymarine
ModelNumber : OC15SUK08
PartNumber : E70100
Pattern : Solid
ProductDescription : Autopilot Control Unit (ACU)

The rugged ACU (Actuator Control Unit) delivers reliable autopilot drive power and also provides power to the SeaTalkng bus. Choose the ACU that fits your steering system type.

Drive Current Output
Maximum continuous 30 Amps at supply voltage
Drive Clutch Output

• Up to 4 Amp continuous at 12V on 12V systems

• Up to 4 Amp continuous at 24V on 24V systems

• Up to 4 Amp continuous at 12V on 24V systems

Connections

• Rudder reference sensor

• Sleep switch

• Power

• Drive motor

• Drive clutch

• Ground

• Digital Input / Output (DIO)

Nominal supply voltage
12 V or 24 V
Operating voltage range
10.8V to 31.2V dc
Power Consumption (standby) - Main Power Supply
300 mA (12/24V)
Power Consumption (standby) - SeaTalkng Power Supply
20 mA (12V)
SeaTalkng LEN (Load Equivalency Number)
1
SeaTalkng Power Out
3 Amp at 12V (fuse protected at 3 Amp)
Data Connections
SeaTalkng

Installation Environment

• Operating Temperature: -20°C to +55°C (-4°F to +131°F)

• Storage T
  ProductSiteLaunchDate : 2014-05-31T02:05:14.882Z
  ScreenSurfaceDescription : Glossy
  SpecificUsesForProduct : personal
  Style : Music
  UnitCount : 1
  UnspscCode : 25170000
