Specification
Brand : Tiny-Clutch
BulletPoint : Price For: Each Finish: Plain Item: Machine Key Material: Steel Application: Holds Pulleys and Gears on Transmission Shafts Type: Undersized Tensile Strength (PSI): 64, 000 psi Length: 1" Thickness Tolerance: -0.002" Length Tolerance: -0.030" Rockwell Hardness: B85 Square: 1/4" End Type: Square Country of Origin (subject to change): United States
BulletPoint1 : Maximum Torque = 15lbs-in (1.7Nm) | Maximum Speed = 5,000 RPM
BulletPoint2 : 3/8 inch (9.5mm) bore with a keyway and set screw.
BulletPoint3 : 20 tooth, 20 pitch, 14.5 degree pressure angle gear.
BulletPoint4 : Power may be applied through either the gear or the cam.
BulletPoint5 : Clutch drives clockwise and slips counter clockwise.
ExternallyAssignedProductIdentifier1 : 0698672038713
ExternallyAssignedProductIdentifier2 : 698672038713
ItemName : Tiny-Clutch 2874-RH Overrunning Gear Clutch
ItemPackageDimensions_Height : 2.5 centimeters
ItemPackageDimensions_Length : 1.9 centimeters
ItemPackageDimensions_Width : 2.5 centimeters
ItemPackageQuantity : 1
ItemTypeKeyword : industrial-brake-and-clutch-accessories
Manufacturer : Helander Products, Inc.
Material : Cam
ModelNumber : 2874-RH
NumberOfItems : 1
PartNumber : 2874-RH
ProductDescription : The Tiny-Clutch 2874-RH overrunning gear clutch is a miniature roller and cam type one-way clutch from our D-Series line of clutches. The D-Series clutches are most frequently used to allow a driven member to overrun the input, or for backstopping a load, they can also function to convert oscillating motion to rotary motion. These clutches use our proven cam and roller principle for long life with trouble free performance. The cam, housing and rollers are made of hardened steel and each roller is energized by a spring which is held square and centered in a drilled pocket. The design of the clutch allows for near zero backlash as well as high free-wheeling speeds. The clutch will not jam in the free direction. The 2874-RH overrunning gear clutch is based on our D93A roller clutch and features a 20 tooth, 20 pitch, 14.5 degree pressure angle gear. This clutch drives counter clockwise and slips counter clockwise, has a 3/8 inch (9.5mm) bore, the cam is screwed and/or keyed to your shaft, and power may be applied to the clutch through either the gear or the cam. These clutches can be used for many different applications and are the original equipment clutches for multiple brands of hot stamping machines.
ProductSiteLaunchDate : 2016-11-29T13:34:36.106Z
Size : One Size
